Allen Bradley 1746-OBP16 Economic DC Output Module

Allen Bradley 1746-OBP16 Economic DC Output Module

    The Allen Bradley 1746-OBP16 is a cost-effective digital output module designed for discrete control systems. It provides reliable sinking-type outputs suitable for various industrial automation applications.

Model Type:SLC500

Model Number:1746-OBP16

Manufacturer:Allen Bradley

Module Type:Digital DC Output Module

Number of Channels:16

Input Voltage:24 VDC

Output Voltage Range:10 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load:1 MA

Current Rating – Backplane:0.28 A

Continuous Current per Output:0.25 A at 60 DEG C

Continuous Current per Module:4 A at 60 DEG C

Communication Circuit Isolation:500 VDC

Backplane Isolation:1500 VAC

Processor:SLC 500

Enclosure Type:Open Type

Mounting Method:Chassis

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95%

    The AB 1746-OBP16 Economic Digital DC Output Module is a robust and cost-effective solution designed for demanding industrial environments. This module supports up to 16 channels of digital output, making it highly versatile for different applications. Its open-type enclosure ensures optimal performance in challenging conditions, while the chassis mounting option provides secure installation. With a wide input voltage range of 24 VDC and an output voltage range of 10 – 50 VDC, this module is suitable for a variety of control tasks. It features low on-state voltage drop and minimal off-state output leakage, ensuring high efficiency and reliability. The module is isolated from communication circuits and backplane by 500 VDC and 1500 VAC respectively, enhancing its durability and safety. The temperature rating of 0 – 60 DEG C and environmental conditions of 5 – 95% humidity make it ideal for industrial settings. Easy to install and maintain, the AB 1746-OBP16 is a valuable asset for any automation system.
