    The Allen Bradley 1769-ADN Analog Input Module is designed for seamless integration into Allen-Bradley’s ControlLogix system. It provides precise analog input capabilities, ensuring reliable data acquisition for various industrial applications including manufacturing, processing, and automation.

Manufacturer:Allen Bradley

Model Number:1769-ADN

Module Type:Analog Input Module

Number of Channels:8 channels

Signal Range:-10V to +10V

Resolution:12-bit

Sampling Rate:Up to 100 samples/second

Power Requirements:24 VDC

Operating Temperature:-40°C to +85°C

Dimensions:30 mm (W) x 80 mm (H) x 85 mm (D)

    The Allen Bradley 1769-ADN Analog Input Module is meticulously designed for integration into existing industrial control systems, enhancing the accuracy and reliability of analog signal processing.

    This module features 8 channels capable of handling both ±10V and 0-10V input ranges, making it highly versatile for various applications.

    With a resolution of 12 bits, this module ensures high precision in signal measurement, supporting up to ±0.1% accuracy of full scale.

    Engineered for durability, the Allen Bradley 1769-ADN can operate within a broad temperature range from -25°C to +70°C, ensuring consistent performance even under extreme conditions.

    Installation is straightforward, thanks to its compatibility with Allen Bradley’s 1769 I/O modules, allowing for easy integration without additional hardware requirements.
