Allen-Bradley 1769-PA4 Conformal Coated Power Supply Module
The Allen-Bradley 1769-PA4-CC is a conformal coated power supply designed for use in industrial automation systems. It provides reliable power delivery and protection against harsh environments, making it ideal for applications in manufacturing facilities and other industrial settings.
Input Voltage Range:85…265V AC or 170…265V AC, switch selectable
Nominal Input Voltage:120V/220V AC
Output Voltage:5.0V and 24VDC
Current Capacity:4.0A at 5.0V and 2.8A at 24VDC
Power Consumption:100 VA @ 24V DC
Fuse Type:Wickmann 19193-6.3A / Littelfuse 021706.3MXP
Mounting:Panel or DIN Rail
Dimensions:118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.)
Weight:630 g (1.39 lb)
The Allen-Bradley 1769-PA4-CC Conformal Coated Power Supply provides a dependable power solution for industrial automation systems. It is specifically designed for the CompactLogix series, offering efficient power conversion with a nominal input voltage of 24VDC and an operational range from 19.2VDC to 31.2VDC.
This power supply is equipped with a high-quality fuse, either Wickmann 19193-6.3A or Littelfuse 021706.3MXP, ensuring reliable circuit protection. Its conformal coating enhances its resistance to moisture, dust, and corrosive agents, making it suitable for operation in challenging industrial environments.
The compact size of the power supply, measuring 118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.), allows for easy installation and space-saving design within control panels. It can be mounted either on a panel or DIN rail, providing flexibility in installation options.
With a weight of just 630 grams (1.39 lbs), this power supply is lightweight yet durable, making it easy to handle during installation and maintenance processes. Its power consumption at 24V DC is rated at 100 VA, ensuring efficient energy usage.
This product is an essential component for any industrial control system looking for reliable power delivery. Whether you’re upgrading existing machinery or building new automation systems, the Allen-Bradley 1769-PA4-CC Conformal Coated Power Supply offers the robust performance and durability needed in today’s demanding industrial settings.
