Allen Bradley 2094-AC05-MP5-S Servo Drive / Multi-Axis Module
The Allen Bradley 2094-AC05-MP5-S Servo Drive is a high-performance integrated axis module and multi-axis servo drive, specifically designed for industrial automation applications requiring robust and efficient control solutions. It supports a wide AC input voltage range and offers precise velocity and current loop frequencies, making it ideal for demanding environments.
Manufacturer:Allen Bradley / Rockwell Automation
Model Number:2094-AC05-MP5-S
Type Designation:Servo Drive / Axis Module
Input Voltage Range:195 to 264 Volts AC 3-phase
Input Frequency Range:47 to 63 Hertz
Velocity Loop Frequency:500 Hz
Current Loop Frequency:1300 Hz
PWM Frequency:8 kHz
Rated Efficiency:95%
Capacitance:75 μF
Capacitive Energy Absorption:10 Joules
Internal Shunt Resistor:115 Ohms
Shunt-on Voltage:805 VDC
Shunt-off Voltage:765 VDC
Operating Temperature:-10°C to +60°C
Enclosure Rating:NEMA/UL Type 1, IP 20
The Allen Bradley 2094-AC05-MP5-S Servo Drive is meticulously engineered to provide superior performance in a wide range of industrial control applications. With its high-precision velocity and current loop frequencies, this servo drive ensures exceptional accuracy and responsiveness.
Designed for seamless integration into existing systems, this multi-axis module supports an extended AC input voltage range, making it versatile for various operational environments. Its robust construction guarantees longevity and reliability.
The module is equipped with advanced Pulse Width Modulation (PWM) technology, which enhances efficiency and minimizes energy consumption. Additionally, it boasts a high-rated efficiency of 95%, contributing to overall system performance and sustainability.
Key features include a built-in internal shunt resistor that aids in thermal management and enhances the drive’s operational stability. The capacitance and capacitive energy absorption specifications further enhance its performance in dynamic control scenarios.
This servo drive is easy to install and maintain, featuring user-friendly interfaces and comprehensive documentation. It is an ideal choice for industries looking to upgrade their control systems for enhanced productivity and efficiency.
