Allen-Bradley 2094-BM01-S*2 Multi-Axis Module for Kinetix 6000 Drive System
The Allen-Bradley 2094-BM01-S*2 Axis Module is an essential component of the Kinetix 6000 Multi-Axis Drive Servo system, designed for high-performance industrial applications requiring precise control and robust safety features.
Current Rating:150% standard peak inverter current rating
Efficiency:98%
Internal Shunt Resistor:115 Ohms
Input Voltage Range:360-480V nominal
Peak Power:5.6 kW
Weight:5.6 pounds (2.54 kilograms)
Safety Feature:Integrated Safe-Torque Off (STO) safety functionality up to SIL 3 and PLe
The Rockwell Automation 2094-BM01-S*2 is a high-efficiency multi-axis module, crafted for demanding industrial applications where precision and reliability are paramount. It features a robust design with an integrated Safe-Torque Off (STO) safety function, making it suitable for applications requiring up to Safety Integrity Level (SIL) 3 and Performance Level (PLe). With its integrated shunt resistor and efficient heat dissipation capabilities, this module ensures optimal performance under strenuous conditions.
This module is a single wide unit that can support up to seven axes per eight-axis power rail, allowing for flexible configuration in various machinery setups. The 2094-BM01-S*2 is designed for applications that demand rapid acceleration and deceleration, thanks to its standard peak inverter current rating of 150%, which can increase up to 250% with the peak enhanced option.
Engineered with meticulous attention to detail, the 2094-BM01-S*2 boasts a continuous current (rms) of 10.3 Amperes and a continuous current (sine) of 14.6 Amperes, ensuring consistent and reliable operation. Its efficiency stands at an impressive 98%, and it can handle symmetrical, short circuit currents of up to 200,000 Ampere (rms).
With a weight of 5.6 pounds (2.54 kilograms), the 2094-BM01-S*2 is lightweight yet durable, making it easy to install and maintain. The integrated shunt resistor with continuous power of 50 Watts and peak power of 5.6 kW adds to its durability and performance reliability.
