GE DS2020SVSAG2 Seismic and Vibration Safety Panel Module

GE DS2020SVSAG2 Seismic and Vibration Safety Panel Module

    The DS2020SVSAG2 is a seismic vibration safety panel module designed by General Electric for use in the Mark V series systems. It ensures safe operation under extreme conditions by detecting seismic and vibration threats, adhering to Universal Building Code standards.

Manufacturer:General Electric

Series:Mark V

Part Number:DS2020SVSAG2

Acronym:SVSA

Seismic Capability:Universal Building Code (UBC) Seismic Code section 2312 Zone 4 compliant

Vibration Tolerance:1.0 G horizontal, 0.5 G vertical at 15 to 120 Hz

Redundancy Modes:Triple Modular Redundant (TMR) or Simplex Redundancy

Power Supply:Accepts multiple DC power sources

Dimensions:16.7 cm x 14.8 cm x 5.5 cm

Weight:0.64 kg

    The DS2020SVSAG2 is an integral part of General Electric’s Mark V control system series, specifically designed for applications requiring seismic and vibration monitoring. This module is built to withstand harsh industrial environments, meeting Universal Building Code standards for seismic safety.

    The panel boasts high tolerance for vibrations ranging from 15 to 120 Hz, making it suitable for a variety of steam and gas turbine applications. It supports both Triple Modular Redundant (TMR) and simplex redundancy modes, ensuring reliability and operational continuity even under demanding conditions.

    Designed for flexibility, this seismic and vibration sensing panel can accept power from multiple sources, including direct current, thus providing adaptability in diverse power supply scenarios. Its compact design ensures easy integration into existing control systems without compromising on performance.

    Whether you’re managing a power plant or overseeing industrial operations, the DS2020SVSAG2 offers peace of mind with its robust construction and reliable performance, backed by General Electric’s reputation for excellence in industrial automation solutions.
