GE DS3800NHVE1B1A High Voltage Board for Mark IV Gas/Turbine Control System
The DS3800NHVE1B1A is a high voltage printed circuit board designed by GE for the Mark IV gas or steam turbine control systems. It provides automated startup/shutdown procedures and monitors water, air, and fuel emissions, ensuring efficient turbine operation.
Board Type:High-Voltage PCB
Compatibility:For use with GE Mark IV systems
Connector Type:2-pin four-position and vertical pin (male) communication connectors
Indicators:Six LEDs
Contact Points:Six contact points
Jumpers:Five jumpers settable to H or B
Resistors:Carbon composite and ceramic-covered metal film resistors
Capacitors:Various values
Alignment Markings:Letters and numbers on two edges
Drilled Center:Factory-drilled dead-center and in all corners
The DS3800NHVE1B1A high-voltage board is an integral component of General Electric’s Mark IV turbine control systems, meticulously engineered to streamline gas and steam turbine operations.
Featuring precise alignment markings and robust connectivity options, this board ensures accurate installation and seamless integration within existing systems.
With its advanced automation features, the DS3800NHVE1B1A facilitates automated startup and shutdown sequences, enhancing operational efficiency.
The inclusion of multiple LEDs and contact points allows for real-time monitoring and interaction, critical for maintaining optimal turbine performance.
Designed with both carbon composite and ceramic-covered metal film resistors, the board exhibits superior durability and reliability under various operating conditions.
Perfect for industries requiring stringent control over their energy production processes, the DS3800NHVE1B1A represents a pinnacle of engineering excellence.
