GE DS3820MSAB1A1A – Core Component for Industrial Control Systems
The DS3820MSAB1A1A is a specialized printed circuit board developed by GE for the Mark IV series, which is utilized in managing gas/steam turbines. It integrates advanced microcomputers to monitor turbines for critical parameters and enables automation of vital procedures such as speed control, startup, shutdown, and more.
Manufacturer:General Electric
Model Number:DS3820MSAB1A1A
Series:Mark IV
Function:Core Module for Turbine Control
Features:Integrated Microcomputers, DIN Rail System, Jumper Switches, Test Points, Transistors, Oscillating Chips, Hex Buffers, J-K Negative Edge Triggered Flip-Flops
Connectors:One Six-Pin Header, One PCB Mating Connector (218A4837-P12)
Dimensions:Size may vary, refer to datasheet
Weight:Refer to datasheet for exact weight
Certifications:Complies with industry standards for safety and reliability
The DS3820MSAB1A1A is a high-quality component from General Electric, specifically engineered for the Mark IV series turbine control systems.
It plays a crucial role in monitoring gas/steam turbines for issues such as over-speed, flame, over-temperature, and high pressure.
Featuring an integrated microcomputer framework, it provides continuous surveillance and automation capabilities like speed control, start-up, shut-down, and sequence control.
Designed with practicality in mind, this board includes a DIN rail system for secure installation, ten jumper switches for customization, and six test points for easy maintenance.
With its advanced components such as oscillating chips, hex buffers, and J-K negative edge triggered flip-flops, the DS3820MSAB1A1A ensures reliable performance in industrial environments.
The board also features a sturdy metal frame with pre-drilled screw holes, making it simple to install and secure.
