GE IC3600QOXC3 Over-Speed Sensor Card for Mark I-II Turbine Control Systems
The IC3600QOXC3 from General Electric is a critical component in the Speedtronic Mark I-II system designed for turbine control. As an over-speed sensor card, it ensures the safe operation of turbines by detecting and responding to excessive rotational speeds.
Brand:General Electric
Model:IC3600QOXC3
Category:Speedtronic Mark I-II System Components
Function:Over Speed Sensor Card
Compatibility:Designed for Speedtronic Mark I-II Systems
Transformer:Large black transformer on the left half of the board near the center
Resistors:Various colored resistors including white, red, orange, and solid black resistors without bands
MOV:At least two (2) Metal Oxide Varistors near the upper edge of the board
Transistors:Small round and silver transistors, black half-circle shaped transistors
The IC3600QOXC3 Over Speed Sensor Card is meticulously crafted by General Electric for use within the Speedtronic Mark I-II turbine control systems.
Designed to detect and prevent overspeed conditions, this sensor card plays a vital role in safeguarding machinery from potential damage.
Its robust construction includes a large transformer located towards the left side of the board, providing reliable power distribution.
Multiple resistors with colored bands indicate specific values, while solid black resistors contribute to the board’s functionality without external markings.
Additionally, two Metal Oxide Varistors (MOVs) are strategically placed near the upper edge of the board to protect against voltage surges.
Various small transistors, including both round silver and half-circle black types, work in tandem to process signals efficiently, ensuring precise monitoring and response times.
