GE IS200EGPAG1BD – Mark VI Excitation Control Module

GE IS200EGPAG1BD – Mark VI Excitation Control Module

    The General Electric IS200EGPAG1ABD is a vital component in excitation control systems, designed for superior performance in industrial applications. It acts as an interface between the control system and power bridge, facilitating precise control over SCRs with direct interfaces for conduction feedback, air flow, and temperature monitoring.

Board Type:Gate Pulse Amplifier Board

Model Number:IS200EGPAG1ABD

Manufacturer:General Electric

Series:EX2100 Excitation Control

Configurable Hardware:5 On-board Jumpers

Weight:1 lbs 9 oz

Discontinued:Yes, contact AX Control for available surplus

Function Interface:Control to Power Bridge

Acronym:EGPA

Instruction Manual Number:GEI-100461 (GEH-6632 Series Manual)

Notable Components:On-board Green and Red LED Indicators

Repairable:Yes

OEM / Manufacturer:General Electric, GE Industrial Systems

    The IS200EGPAG1ABD is a high-performance Gate Pulse Amplifier Board specifically designed for the EX2100 Excitation Control System.

     It features five onboard jumpers that allow for configuration and customization of the hardware according to specific requirements.

     Equipped with green and red LED indicators, it provides clear operational feedback, making maintenance and troubleshooting straightforward.

     The board directly controls Silicon Controlled Rectifiers (SCRs), serving as the interface for conduction feedback, air flow, and temperature monitoring.

     With a weight of just 1 lb 9 oz, it is lightweight and easy to install.

     Additionally, repair services are available through AX Control, ensuring your system remains up and running without interruption.
