GE SR745-W2-P1-G1-HI-E-H, Advanced Transformer Management System for Industrial Control
The GE SR745-W2-P1-G1-HI-E-H is an advanced industrial transformer protection system designed to monitor and safeguard transformers, autotransformers, and reactors. It offers a large 40-character display for easy viewing and expanded keypad for efficient manual entry of setpoints.
Windings Per Phase:2
Resistant Temperature Device (RTD) Type:3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
Dimensions:Height: 9 inches, Depth: 7 ⅛ inches, Width: 7 inches
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
The GE Multilin SR745-W2-P1-G1-HI-E-H Transformer Protection System enhances system reliability and efficiency through advanced monitoring capabilities.
Designed specifically for two-winding transformers, this system minimizes downtime by proactively detecting potential faults and issues, thereby extending the lifespan of transformer assets.
Its large 40-character display and expanded keypad facilitate easy manual entry of setpoints, enhancing user convenience.
Mounted on a standard 19-inch panel, the system ensures compatibility with existing infrastructure.
With features like Hottest Spot Monitoring, users gain valuable insights into operational status, allowing for timely interventions.
The compact design and robust construction make it ideal for industrial environments where space is limited and performance is critical.
