GE VMIVME2534 High Voltage Digital I/O Board

GE VMIVME2534 High Voltage Digital I/O Board

    The VMIVME-2534 from General Electric is a high voltage Digital Input and Output Board designed for industrial automation control systems. With 32 bits of high voltage outputs and capable of handling up to 600 milliamperes, this board ensures reliable operation in demanding environments.

Manufacturer:General Electric

Model:VMIVME2534

Bits of High Voltage Outputs:32

High Current Sink:600 mA

High Breakdown Voltage:60 V DC

Output Clamps Diodes:Yes

Overcurrent Protection:1 A

Thermal Limit Protection:Yes

Load Driver Model:UDN2549B

Input Groups:8

Jumper Selectable Inputs:Yes

Open Circuit Detection:Yes

    The GE VMIVME2534 is a high-quality digital I/O board meticulously designed for industrial control systems. This module supports 32-bit high voltage outputs, making it ideal for applications requiring precise control signals. Equipped with a high current sink capacity of 600 milliamperes, this board is capable of handling substantial loads. Furthermore, the board includes a series of output clamp diodes and offers robust protective features against overcurrent conditions up to 1 ampere and thermal limits. The integrated UDN2549B load driver is suitable for incandescent and inductive loads, ensuring smooth operation in various scenarios. Additionally, the 32-bit high voltage inputs are configured into 8 inputs, providing flexibility for monitoring and control purposes. Each input is jumper selectable, allowing for easy customization based on specific application requirements.
