Honeywell C7061A Ultraviolet Sensor Module – Dynamic Self-Check Function
The Honeywell C7061A Ultraviolet Sensor Module is designed for industrial flame detection systems. Featuring dynamic self-checking functionality, this module ensures reliable performance and safety in harsh environments. It is ideal for gas and oil-fired burners, offering superior harmonic reduction and built-in vector control.
Model Number:C7061A
Sub-model:A1012
Sensing Element:Ultraviolet Sensing Tube
Mounting Flange:With Protective Heat Block
Connector Type:Brad Harrison Type
Operating Voltage:120 Vac
Frequency:50 Hz; 60 Hz
Lead Wire Length:2438 mm
Ambient Temperature Range:-40 C to +79 C
Explosion-Proof Rating:Meets NEMA 4 Standards (C7061E) / Explosion-Proof Housing (C7061F)
Pressure Rating:Viewing Window Rated to 20 psi (C7061E) / 100 psi (C7061F)
The Honeywell C7061A Ultraviolet Sensor Module is a robust solution for flame detection in industrial environments. It includes a dynamic self-check function that ensures continuous reliability and safety.
Equipped with a UV sensing tube rated to -40 F (-40 C), this sensor module is designed to withstand harsh conditions. It comes with a color-coded leadwire setup for easy and rapid electrical installation.
This model meets NEMA 4 standards, making it suitable for applications requiring protection against splashing water and dust. With a pressure rating of 20 psi for the C7061E and 100 psi for the C7061F, it offers enhanced safety in demanding environments.
The C7061A is built with a protective heat block integrated into its mounting flange, providing additional durability. It operates within a wide temperature range from -40 C to +79 C, ensuring consistent performance under varying conditions.
For applications prone to frequent false alarms, two detectors can be wired in parallel to minimize unnecessary shutdowns. This feature enhances operational efficiency and reduces downtime.
