HP 8116A Pulse/Function Generator, High Precision Electronic Testing Equipment
The HP 8116A Pulse/Function Generator is a high-performance signal generation device designed for testing electronic circuits. It provides precise control over frequency, amplitude, and waveform shapes, making it ideal for use in engineering labs and manufacturing environments.
Frequency Range:10 Hz to 1 MHz
Output Amplitude:10 mVpp to 10 Vpp
Waveform Types:Sine, Square, Triangle, Ramp, Pulse
Voltage Accuracy:+/- 1% of setting + 2 mV
Impedance:50 Ohms
The HP 8116A Pulse/Function Generator is a high-performance instrument that enables precise control over waveform parameters. It supports a wide range of waveforms including sine, square, triangle, ramp, pulse, and DC signals, making it ideal for various electronic testing needs. With a frequency range from 0.001 Hz to 10 MHz and an amplitude range of 2 mVpp to 20 Vpp, this generator ensures accurate and reliable signal generation. Its resolution of 1 μHz allows for fine-tuning, while harmonics up to the 10th order can be controlled for complex waveform creation. The generator’s low distortion (<0.1%) guarantees high-quality signal output, and its 50 ohm output impedance ensures compatibility with a wide array of test setups.
