KOLLMORGEN U12M4H ServoDisc Motor – High Precision Industrial Control Component

KOLLMORGEN U12M4H ServoDisc Motor – High Precision Industrial Control Component

    The KOLLMORGEN U12M4H Servo Disc Motor offers high precision control, ideal for applications requiring accurate positioning and smooth operation. Designed for industrial automation systems, this motor ensures reliable performance under demanding conditions.

Brand:KOLLMOGEN

Model:U12M4H

Item No.:00-01203-999

Operating Voltage:220V (AC)

Rated Current:4.8A

Rated Active Power:750W / 0.75kW

Rotational Speed:3000rpm, 6000rpm (maximum)

Torque:2.4Nm nominal, 8.4Nm maximum

Moment of Inertia:0.000137kg.m2 (1.37kg.cm2)

Resolution:22-bit absolute feedback encoder

Cooling Method:Natural Cooling

Design Features:Keyed shaft, built-in e/m brake

    The KOLLMORGEN U12M4H Servo Disc Motor is an essential component for precise control in industrial automation systems. Its robust design includes a built-in absolute feedback encoder with a resolution of 22 bits, ensuring accurate positioning and reliable operation under demanding conditions.

    With its high-speed capabilities up to 6000rpm and torque output of up to 8.4Nm, this motor is ideal for applications requiring rapid response and high performance. The natural cooling system ensures efficient heat dissipation without the need for additional cooling mechanisms.

    The motor’s keyed shaft design provides secure and stable rotation, while the built-in electro-mechanical brake offers immediate stopping power when needed. This feature is crucial for safety and precision control in dynamic environments.

    Designed with a low moment of inertia, the U12M4H motor offers quick acceleration and deceleration, making it suitable for applications where fast response times are critical. Its compact 80x80mm flange mounting configuration allows for easy integration into existing systems.

    The 4-pin rectangular connector simplifies wiring and installation, reducing setup time and increasing efficiency. With its advanced AC brushless technology, the U12M4H motor delivers smooth operation and exceptional durability, making it a top choice for industrial control engineers.
