NI PXIe-7846 High-Performance RF Flexrio Module
The NI PXIe-7846 is a high-performance reconfigurable Field-Programmable Gate Array (FPGA) module designed for complex digital signal processing tasks and system integration in industrial automation and test systems.
Module Type:High-Speed Digital Pattern Generator and Analyzer
Form Factor:PXI Express (PXIe)
Channels:Up to 16 channels
Sampling Rate:Up to 200 MS/s per channel
Resolution:8-bit
Voltage Range:-10 V to +10 V
Clock Frequency:Up to 100 MHz
Interface:PCI Express x4
Power Consumption:12W (Typical)
Weight:0.5 kg
Dimensions:4-slot PXI Express module
The NI PXIe-7846 combines high-speed digital pattern generation and analysis capabilities in a compact PXI Express form factor, enabling engineers to perform precise and reliable testing on their devices under test.
With up to 16 channels, each capable of sampling at rates up to 200 MS/s, the PXIe-7846 provides the necessary speed and precision required for complex signal integrity and compliance testing. This makes it a valuable tool for validating designs against industry standards.
Built-in features such as programmable voltage ranges from -10V to +10V allow for versatile testing scenarios. Additionally, the PXIe-7846 supports a wide range of clock frequencies, ensuring compatibility with various system requirements.
The user-friendly interface and robust software tools provided by National Instruments make setup and operation of the PXIe-7846 straightforward, even for those without extensive experience in digital testing.
Designed with reliability and durability in mind, the PXIe-7846 offers consistent performance over long periods of use, with low power consumption and a compact design that fits easily into standard PXI chassis.
