Rockwell Automation MPL-A430P-SK72A AMP-Series 240V AC Rotary Servo Motor
The Rockwell Automation MPL-A430P-SK72A is a high-performance 240V AC rotary servo motor from the AMP-Series. This motor offers exceptional reliability and efficiency, making it ideal for industrial automation applications requiring precise control and robust performance.
Voltage Rating:240V AC
Power Rating:400W
Current Rating:2.5A
Speed Range:0 – 4000 RPM
Torque:2.2Nm
Rotor Inertia:0.0004 Kg·m²
Control Method:Sinusoidal Commutation
Connector Type:MS Connectors
Shaft Diameter:12mm
Shaft Length:50mm
Weight:2.3kg
This robust rotary servo motor from Rockwell Automation’s AMP Series is engineered for durability and precision. It features an IP65-rated enclosure ensuring protection against dust and water splashes, making it suitable for harsh industrial environments.
The MPL-A430P-SK72A comes equipped with a 2500 PPR incremental optical encoder, providing accurate position feedback which is crucial for achieving precise control in automated machinery. The encoder supports two channels in quadrature, complemented by a channel marker pulse for enhanced performance.
The motor is designed with mating MS connectors for power and encoder connections, simplifying installation and reducing the risk of connection errors in complex setups. This feature is particularly advantageous in applications involving multiple motors or sensors.
With its 4000 RPM maximum speed and 2.6 Nm torque, this servo motor can handle demanding tasks with ease, making it ideal for a wide range of industrial applications such as packaging, assembly lines, and material handling systems.
The high efficiency of this motor is achieved through advanced brushless sinusoidal commutation technology, ensuring smooth operation and reduced wear on mechanical components over time. Additionally, the motor includes optional integrally mounted brakes available with coil voltages of 90 VDC or 24 VDC, providing reliable stopping power when needed.
