Rockwell MPL-B420P-HK72AAMP Series 480V AC Rotary Servo Motor

Rockwell MPL-B420P-HK72AAMP Series 480V AC Rotary Servo Motor

    This high-performance AC brushless rotary servo motor from Rockwell Automation’s MPL-B420P-HK72AAMP-Series is designed for industrial applications requiring precision control. Featuring a compact design, this motor offers reliable operation at 480V AC supply voltage, delivering exceptional torque and speed performance.

Supply Voltage (AC):480V

Rated Current:4.8A

Rated Power:750W / 0.75kW

Rotational Speed:3000rpm, 6000rpm (maximum)

Torque:2.4Nm nominal

Maximum Torque:8.4Nm

Moment of Inertia:0.000137kg.m2 (1.37kg.cm2)

Connection Type:4-pin rectangular connector

Mounting Mode:80x80mm flange mounting

Resolution:22-bit

    The Rockwell Automation MPL-B420P-HK72AAMP Series 480V AC Rotary Servo Motor is engineered for demanding industrial environments. Its advanced design features include a high-resolution 20-bit absolute encoder for unparalleled accuracy and reliability. This motor is built with a keyed shaft and natural cooling method, ensuring stable operation under heavy loads. The rated power of 3kW and a wide speed range from 0-3000 rpm make it versatile for various applications. It is compatible with flange mounting and includes a 4-pin rectangular connector for easy integration into existing systems. The combination of high torque (up to 7.0Nm) and low inertia (0.00107 kg.m^2) ensures smooth and efficient motion control. Ideal for machinery, robotics, and manufacturing systems, this servo motor delivers precision and reliability, making it a top choice for modern industrial automation.
