Schneider X80-Q BMEXBP0400H Enhanced 4-Slot Ethernet Backplane, Power Supply Non-Occupying Slot
The Schneider X80-Q BMEXBP0400H is a high-performance backplane designed for industrial automation applications. This enhanced 4-slot Ethernet backplane supports dual Ethernet and X-bus connectivity, providing robust performance in harsh environments. The power supply does not occupy any slot positions, making it an ideal choice for systems requiring efficient space utilization.
Product Type:Backplane / Rack
Product ID:BMEXBP0400H
Series:Modicon M340
Slots:4
Ethernet Ports:4
Bus X-Bus Connectors:Yes
Power Consumption:162 mW @ 3.3V DC, 2.8W @ 24V DC
Current Consumption:49mA @ 3.3V DC, 118mA @ 24V DC
Net Weight:0.705 kg
Compatibility:Schneider Electric Modicon M340
Environmental Protection:Conformal Coated PCB
Power Supply:Non-occupying
The Schneider X80-Q BMEXBP0400H is a ruggedized backplane that supports up to four slots for additional modules, including those with Ethernet connectivity. This backplane is specifically designed for the Modicon X80 system, ensuring seamless integration and enhanced functionality.
This product features a conformal coated PCB, making it resistant to harsh environments, thus extending its operational life span and reliability.
With its dual Ethernet and X-bus connectors, the BMEXBP0400H offers flexible networking options and high-speed data transfer capabilities, ideal for complex industrial automation scenarios.
Installation is straightforward, allowing for either panel or plate mounting, providing versatility in deployment across various industrial settings.
This model ensures that power supply does not occupy any of the slots, maximizing the available space for additional modules and improving overall system efficiency.
