Tektronix TDS3054 Digital Phosphor Oscilloscope, 500 MHz Bandwidth, 4 Ch
The Tektronix TDS3054 Digital Phosphor Oscilloscope provides high-performance measurement capabilities with rich visualization. Ideal for engineers and technicians working in design, troubleshooting, and education, this oscilloscope delivers reliable, repeatable results.
Channels:4
Bandwidth:500 MHz
Sampling Rate:2.5 GS/s
Record Length:10k points
Waveform Capture Rate:20,000 wfm/s
Vertical Resolution:8-bit
Display:9-inch TFT LCD
Dimensions:15.2 x 7.2 x 6.1 inches
Weight:11.5 lbs
Interface:USB, Ethernet, GPIB
The Tektronix TDS3054 Digital Phosphor Oscilloscope is designed for professionals who require precise measurement tools. Its advanced DPO technology allows for rapid visualization of transient events and complex signals, providing a complete picture of system performance. The user-friendly interface ensures easy operation even for first-time users. Key features include a large 9-inch TFT color display for clear visualization, four analog channels for comprehensive signal analysis, and a high-speed sampling rate of 1.2 GS/s to capture fast-moving signals. With a bandwidth of 500 MHz, this oscilloscope is capable of handling a wide range of test scenarios from basic debugging to advanced signal integrity analysis. It also includes multiple connectivity options including USB, Ethernet, and GPIB for flexible integration with existing systems.
